1-5/8 EIA Connector (1-5/8 Cable)
1‑5/8" EIA flange connector designed for 1‑5/8" foam coaxial cable.
Mechanical Characteristics
-
Connector type: 1‑5/8" EIA flange connector (sealed by O‑ring)
-
Interface dimensions: per CECC 22150
-
Assembly kit included:
-
4 × M8×35 screws
-
Locknuts
-
Washers
-
O‑rings
-
Electrical Characteristics
-
Impedance: 50 Ω
| Component | Material | Finish |
|---|---|---|
| Coupling flange | Brass | Nickel plated |
| Body | Brass | Nickel plated |
| Center contact | Brass | Silver plated |
| Other metal parts | Brass | Nickel plated |
| Insulator | PTFE | — |
| Gaskets | Silicone rubber | — |
| Hardware kit | Stainless steel | — |
