Technical Specifications

• Gain: 25 dB

• Input Power: 41 dBm

• Supply Voltage: 48V DC

• Bandwidth: 88–108 MHz

• Transistor: 2 x MRF1K50H

• Heatsink: Included

Important Notice – Please Read Before Purchasing

RF amplifier pallets are sensitive devices that require proper handling and technical expertise. If you are not experienced with RF systems, thermal management, or impedance matching, we highly recommend choosing a fully assembled and tested amplifier instead.

Improper use may cause permanent damage. Please avoid the following:

• Applying excessive drive power or supply voltage

• Operating without sufficient heatsinking (although one is included)

• Using filters that do not meet the required specifications

• Connecting mismatched loads or running without a load

• Soldering coaxial leads that are too long or improperly connected

Due to the sensitive nature of these modules, no warranty is provided. However, we assure you that each pallet is thoroughly tested and 100% operational before leaving our workshop.
