BPF3-20K- 20KW FM Triple Cavity Filter

20 kW FM Band PassTriple Cavity Filter

Specifications

Mechanical properties

  • Connector EIA 3 1/8"
  • Overall Dimensions [mm.] 1786x558x1159
  • Weight [kg.] 120
  • Temperature range [° c] -10 ÷  50



Electrical properties

  • Frequency range [MHz] 87.5 ÷ 108
  • Maximum input power [W] 20000
  • Insertion loss [dB] @ fo < 0.25
  • Insertion loss [dB] @ fo ± 150kHz <0.3
  • Selectivity [dB] @ Fo ± 1.2 MHz> 24
  • Return loss [dB] > 26
  • Input / output impedance 50 Ohm
