echnical Specifications

• Gain: 25 dB

• Input Power: 44 dBm

• Supply Voltage: 48V DC

• Bandwidth: 88–108 MHz

• Transistor: 4 x MRF1K50H

• Heatsink: Included

Important Notice – Please Read Before Purchasing

RF amplifier pallets are sensitive components that require careful handling and expertise. If you do not have experience with RF systems, thermal management, or impedance matching, we highly recommend purchasing a fully assembled and tested amplifier instead.

Improper usage may cause permanent damage. Please avoid the following:

• Applying excessive drive power or supply voltage

• Operating without a suitable heatsink (one is included)

• Using filters that do not meet the necessary specifications

• Connecting mismatched loads or running with no load

• Soldering coaxial leads that are too long or improperly connected

Due to the sensitive nature of these devices, no warranty is provided. However, we guarantee that every pallet is thoroughly tested and fully operational before shipping.
