Mechanical Characteristics:

• Connections : EIA 1-5/8
• Overall dimensions [WxDxH][mm.] : 205x205x295
• Temperature range [°C] : -10 ÷ +50
• Weight [kg.] : 6.5

Electrical Characteristics:

• Frequency Range [MHz] : DC to 862
• Insertion Loss [dB] : <0.05
• Input/Output impedance [Ohm] : 50
• Operating Voltage [Vac]: 220÷230 / 50÷60 Hz
• Control voltage [Vdc] : 5, 12 or 24
• Switch-over time[s] : < 3.3
